Guide TB430 Thermal Clip On

The TB Series revolutionises hunting equipment by seamlessly integrating precision and portability. Its magnesium alloy housing not only reduces weight but also enhances accuracy, making it over 20% lighter than comparable products. With it’s 400 x 300 @12μm sensor, 35mm lens and Full-HD AMOLED display boasting wider viewing angles and richer colours, the TB430 sets a new standard in relaxed hunting experiences.

Features:

• 12μm advanced thermal detector, NETD<25mK
• Full-HD 1920×1080 AMOLED display
• Magnesium alloy housing, compact design, light weight but powerful
• Detection range up to 1800m
• Two Standard 18650 batteries provides up to 12 hours of operation
• Double Side focus knob for easy operation
• Video recording including sound
• IP68, Shock resistance up to 1000G/ms

Specifications:

Sensor
Type: Uncooled VOx Infrared Detector, 8 to 14 μm
Resolution: 400×300@12μm
NETD: 25mK
Frame rate: 50Hz

Lens
Objective lens: 35mm, F1.0
Field of view: 7.8°×5.9°
FOV m @100m: 14×10
Magnification: 1x
Detection range: 1400m/yd

Display
Display type: 0.39’’ AMOLED 1920x1080
Eyepiece: Exit pupil distance 20mm; Zoom: 6.4x

Hardware
WIFI: 2.4G, 5G
Interface: USB Type-C (Power supply/USB2.0)
Others: Microphone, Bluetooth

System
Recording function: Photo/Video
Memory capacity: 32GB

Power
Battery type: 2 replaceable 18650 batteries
Operating time: 12 hours

Environmental
Operating temp.: -20 °C to 50 °C/ -4°F to +122°F
Shock: 1000 G at 1 ms half sine pulse (as per IEC60068-2-27)
Encapsulation: IP68

Physical
Weight(g/ oz): 425/ 14.99
Size(mm/ in): 128×79×79/ 5.04×3.11×3.11
Standard: A device, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card
Optional: 18650 battery, Bluetooth remote control, Cover ring adapter

Cover ring adapter
A: Weight 70 g, Compatible with 38/ 40/ 42/ 44/ 46 mm
B: Weight 80 g, Compatible with 48/ 50/ 52/ 54 mm
C: Weight 90 g, Compatible with 56/ 58/ 60/ 62/ 64 mm
